LED Chip Brand : philips/Bridgelux
Input Volage : AC100-240V 50/60Hz
Light Efficiency : >100m/W
Color Temperature : 3000K/4500K
Operating Temperature : -40℃ ±60℃
Warranty : 5years
Power Factor : >0.9
Color Rendering Index（Ra) : >70
Viewing Angle :
IP Grade : IP65
Material : Aluminum
Driver Brand :meanwell
This series including different watt : 120 watt , 150 watt , 200 watt ,
240 watt , 300 watt , 360 watt , 500 watt , 600 watt for choose
Harbors
Flood Towers and Parking Area
Sport Stadiums and Areas
Parks and commercial areas
|
Model |
Power |
CCT |
Lumen |
Net weight |
Voltage |
Install height |
|---|---|---|---|---|---|---|
| CY-CA120W | 120watt | 3000-6000K | 2700 | 6.9KG | 100-277V | 7-12M |
| CY-CA150W | 150watt | 3000-6000K | 4500 | 12KG | 100-277V | 10-15M |
| CY-CA200W | 200watt | 3000-6000K | 9000 | 12KG | 100-277V | 12-18M |
| CY-CA240W | 240watt | 3000-6000K | 13500 | 12KG | 100-277V | 18-25M |
| CY-CA360W | 300W/360W | 3000-6000K | 18000 | 18KG | 100-277V | 18-25M |
| CY-CA600W | 500W/600W | 3000-6000K | 27000 | 29KG | 100-277V | 18-25M |
